Common Prop Screw Thread Sizes
- ✓ Tr 36×6 — most common scaffolding prop (India)
- ✓ Tr 40×7 — heavy-duty prop screw
- ✓ Tr 48×8 — extra-heavy prop for high loads
- ✓ M30×3.5, M36×4, M42×4.5 — metric props
- ✓ Custom pitches available on request
Hardev Hydraulics manufactures thread rolling machines for scaffolding prop screws, mechanical jacks and lead screws. Trapezoidal DIN 103 (Tr), Acme and metric thread rolling for M24–M52 diameters. 30% stronger than cut threads — engineered for load-bearing safety.
Scaffolding props (adjustable steel shores) use trapezoidal (Tr) or metric coarse threads on their adjusting screws. Mechanical jacks, screw jacks and lead screws also rely on trapezoidal or Acme threads for efficient power transmission under load.
Thread rolling is strongly preferred for prop and jack screws because cold-rolled threads are 30% stronger than cut threads — critical for load-bearing scaffolding safety. Hardev Hydraulics machines produce precise Tr threads at 15–45 pcs/min on prop screw sizes from M24 to M52.
| HH-JPR Series: Prop & Jack Thread Rolling Machine | |
|---|---|
| Metric Thread Range | M24 – M52 |
| Trapezoidal (Tr) Range | Tr 24×5 – Tr 60×9 |
| Acme Thread Range | 1" – 2.5" (25–63mm) |
| Thread Standards | DIN 103 (Tr), Acme, ISO Metric |
| Machine Type | Three Roll Hydraulic |
| Hydraulic Force | 22 Metric Tons |
| Motor Power | 5.5 kW |
| Production Speed | 15 – 45 pcs/min |
| Thread Type | Standard | Flank Angle | Best For | Available |
|---|---|---|---|---|
| Trapezoidal (Tr) | DIN 103 | 30° | Scaffolding props, lead screws, European jacks | ✓ Yes |
| Acme | ASME B1.5 | 29° | US-standard jacks, lathe lead screws | ✓ Yes |
| ISO Metric Coarse | ISO 68-1 | 60° | General-purpose prop screws, M24–M52 | ✓ Yes |
| Square Thread | Non-standard | 0° | Highest efficiency power screws | On Request |
Share your prop screw size, thread type and daily production target — we'll recommend the right machine with pricing in 24 hours.
